Product Description
Day
Night
● This courtyard light made of aluminum and process die-casting . And the transparent cover is PMMA or PC, with good light conductivity and no glare due to light diffusion. It has milky white or transparent color to choose and use the injection molding process.
● The internal reflector is a high-purity alumina, which can effectively prevent glare.
● We match the energy conservation, environmental protection, high efficiencyThe LED module light source wich is easy installation.
● The regular rated power we macth 30-60 watts, but we can customize any watts as customier like.
● The stainless steel fasteners to use the entire lamp, which are not easy to corrode. On the top of the lamp there is a heat dissipation device , which can effectively dissipate heat and ensure the service life of the light source. After professional test of waterproof can reach IP65.
● We polished the surface of the lamp in order to do the pure polyester electrostatic coating and it aso can can effectively prevent corrosion.
Technical parameters
|
Model
|
JHTY-8007
|
|
Dimension
|
Φ510MM*H570MM
|
|
Fixture Material
|
High pressure die-casting aluminum lamp body
|
|
Lamp Shade Material
|
PMMA or PC
|
|
Rated Power
|
30W to 60W
|
|
Color temperature
|
2700-6500K
|
|
Luminous Flux
|
3300LM 6600LM
|
|
Input Voltage
|
AC85-265V
|
|
Frequency range
|
50/60HZ
|
|
Power factor
|
PF> 0.9
|
|
Color Rendering Index
|
> 70
|
|
Working Ambient Temperature
|
-40℃-60℃
|
|
Working Ambient humidity
|
10-90%
|
|
LED Life
|
>50000H
|
|
Protection Grade
|
IP65
|
|
Install Sleeve Diameter
|
Φ60 Φ76mm
|
|
Applicable Lamp Pole
|
3-4m
|
|
Packing Size
|
600*600*400MM
|
|
N.W(kgs)
|
5.7
|
|
G. W(kgs)
|
6.7
|
Colors and Coating
In addition to these parameters, the JHTY-8007 LED Led Yard Light is also available in a range of colors to suit your style and preference. Whether you prefer a classic black or gray, or a more daring blue or yellow tint, here we can customize them to suit your needs.
Gray
Black
